Model |
Port Size | Temperature (Central Degree) Setting | Accurate | Maximum Operating Temperature | Maximum Operating Pressure | Net Weight | Flow Rate | |||||
°C | °F | °C | °F | °C | °F | MPa | PSI | g | lb | Cv | ||
MD | DN15 | 37/45/55/60/required | 98.6/113/131/140/required | ±2 | ±3.6 | 130 | 266 | 1.0 | 145 | 290 | 0.639 | 1.5 |
DN20 | 335 | 0.738 | 1.5 | |||||||||
Easy installation with pipe wrench
Discharges the minimum amount of water required to prevent freeze damage
Sensitive to temperature only
